Other Systems > Toolholders REGO-FIX CAPTO > End Mill holders WELDON(WD)

TYPE Part. NO Dimensions [mm] Reduction sleeve Ø DXF PDF
D [mm] L [mm] [mm] [Inch]
C3 / WD 6 x 045 2803.30610 6 45
C3 / WD 8 x 045 2803.30810 8 45
C3 / WD 10 x 050 2803.31020 10 50
C3 / WD 12 x 055 2803.31220 12 55
C4 / WD 6 x 050 2804.30620 6 50
C4 / WD 8 x 050 2804.30820 8 50
C4 / WD 10 x 050 2804.31020 10 50
C4 / WD 12 x 055 2804.31220 12 55
C4 / WD 14 x 055 2804.31420 14 55
C4 / WD 16 x 055 2804.31620 16 55
C5 / WD 6 x 050 2805.30620 6 50
C5 / WD 8 x 050 2805.30820 8 50
C5 / WD 10 x 055 2805.31020 10 55
C5 / WD 12 x 060 2805.31230 12 60
C5 / WD 14 x 060 2805.31430 14 60
C5 / WD 16 x 060 2805.31630 16 60
C5 / WD 18 x 060 2805.31830 18 60
C5 / WD 20 x 060 2805.32030 20 60
C5 / WD 25 x 080 2805.32550 25 80
C6 / WD 6 x 055 2806.30620 6 55
